Excavator-420

Excavator-420

Operating Weight (kg) 41,000
Bucket Capacity (m³) 1.9–2.2
Boom Length (mm) 6,550
Arm Length (mm) 3,280
Tonnage (tons) 40
Power Conventional Power
Bucket Backhoe
WhatsApp:+86 18963088836
Email:coco@jcxcsteel.com
Contact Us

Product Description



The WGQ-420 is a 42‑ton class heavy hydraulic crawler excavator designed to deliver maximum productivity in the most demanding large-scale applications, including open-pit mining, mass earthmoving, quarry operations, and major infrastructure projects. With a high-torque engine, an ultra-efficient hydraulic system, and a reinforced heavy-duty undercarriage, the WGQ-420 provides exceptional digging force, fast cycle times, and outstanding reliability for 24/7 operation.

Product Parameters



Operating Weight (kg)41,000
Bucket Capacity (m³)1.9–2.2
Boom Length (mm)6,550
Arm Length (mm)3,280
Tonnage (tons)40
PowerConventional Power
BucketBackhoe
Manufacturer
PowerConventional Power – Diesel Engine
Performance
Swing Speed (rpm)9.5
Travel Speed (km/h)3.3–5.5
Bucket Digging Force (kN)242.1 / 264.6
Arm Digging Force (kN)218.5 / 139.1; 176.4 / 193.1; 152.9 / 166.6
Power System
Engine ModelCummins QSL8.9 (China Stage III)
Rated Power (kW/rpm)243 kW / 2,000 rpm
Cooling MethodWater-cooled
Hydraulic System
Main Pump TypeParallel-axis Swashplate Axial Piston Pump
Main Pump Max. Flow (L/min)2 × 285
Working Hydraulic Circuit Pressure (MPa)Standard 31.4 / Boost 34.3
Travel Hydraulic Circuit Pressure (MPa)26.5
Swing Hydraulic Circuit Pressure (MPa)26.5
Pilot Pump Flow (L/min)24
Dimensions
Overall Transport Length (mm)11,490
Overall Transport Width (mm)3,350
Overall Transport Height (mm)3,575
Cab Height (mm)3,150
Upperstructure Width (mm)2,990
Counterweight Ground Clearance (mm)1,277
Track Ground Contact Length (mm)4,250
Overall Track Length (mm)5,215
Track Shoe Width (mm)600
Overall Track Width (mm)3,350
Track Gauge (mm)2,750
Minimum Ground Clearance (mm)540
Tail Swing Radius (mm)3,660
Working Range
Max. Digging Radius (mm)11,520
Max. Digging Radius at Ground Level (mm)11,310
Max. Digging Depth (mm)7,725
Max. Digging Height (mm)11,000
Max. Dumping Height (mm)7,845
Max. Vertical Digging Depth (mm)4,400
Max. Effective Digging Depth (mm)7,570
