Product Description



The WGQ-350 is a 35‑ton class large hydraulic crawler excavator engineered for high-intensity mining, quarrying, and heavy infrastructure projects. With a high-output engine, a robust hydraulic system, and an extra‑heavy‑duty undercarriage, this machine delivers exceptional productivity, fuel efficiency, and reliability even in the most abrasive environments.

Product Parameters



SpecificationsParameters
Operating Weight (kg)34,600
Bucket Capacity (m³)1.65
Boom Length (mm)6,255
Arm Length (mm)3,150
Tonnage (tons)33-ton Class
PowerConventional Power
BucketBackhoe
Performance
Swing Speed (rpm)11.4
Swing Torque (kN·m)92
Travel Speed (km/h)5.0 / 3.1
Ground Pressure (kPa)56
Bucket Digging Force(kN) 188 / 199.9
Arm Digging Force(kN) 127.5 / 135.3
Power System
Engine ModelNational III Cummins 6CT8.3
Rated Power (kW/rpm)194 kW / 2000 RPM
Displacement (L)8.3
Number of Cylinders6
Operation Type4-stroke, Water-cooled, Direct Injection
Hydraulic System
Main Pump TypeVariable Displacement Axial Piston Pump
Main Relief Pressure Setting (MPa)Standard 27.9 / Boost 34.3
Main Pump Max. Flow Rate(l/min) 2 × 246
Travel Hydraulic Circuit(MPa) 32.5
Swing Hydraulic Circuit (MPa)27.9
Pilot Pump Flow Rate (L/min)28.5
Fluid Capacities
Fuel Tank (L)450
Hydraulic Tank (L)290
Dimensions
Overall Transport Length (mm)10,820
Overall Transport Width (mm)3,300
Overall Transport Height (mm)3,365 (to top of boom)
Cab Height (mm)3,255
Upperstructure Width (mm)2,960
Track Ground Contact Length (mm)4,010
Overall Track Length (mm)4,930
Track Shoe Width (mm)600
Overall Track Width (mm)3,300
Track Gauge (mm)2,700
Min. Ground Clearance (mm)500
Tail Swing Radius (mm)3,200
Working Range
Max. Digging Radius (mm)10,705
Max. Digging Radius at Ground Level (mm)9,950 / 11,105 / 10,540 / 17,320
Max. Digging Depth (mm)7,190
Max. Digging Height (mm)10,495
Max. Dumping Height (mm)7,470
Max. Vertical Digging Depth (mm)6,220
Max. Effective Digging Depth (mm)6,505 / 7,810 / 7,150 / 13,680
